Compiled from teardowns and repair technicians: ILCE-7R IMX094AQR ILCE-7S IMX235AQR ILCE-7M2 IMX157AQL ILCE-7RM2 IMX251AQL ILCE-7SM2 IMX235AQL ILCE-9 IMX310KQL ILCE-7RM3 IMX251AQL ILCE-7M3 IMX410AQL ILCE-9M2 IMX310KQL PXW-FX9 IMX410DQL ILCE-7RM4 IMX451AQL ILCE-7C IMX410AQL ILCE-7SM3 IMX510AQL ILCE-1 IMX610AQL ILME-FX6 IMX510AQL ILME-FX3 IMX510AQL ILME-FR7 IMX510AQL ILCE-7M4 IS-1041 ILCE-7RM5 IMX451AQL ZV-E1 IMX510AQL

It shoots 10bit H.265 or ProRes HQ.

The way 2.7K is derived from 5.5K sensor produces severe aliasing, and no AI superscaling can hide that.

14bit readout on X-H2s absolutely does not offer any tangible benefits. The sensor design cannot take adavantage of higher bit-depth readout as the extra bits are really only there to quantise noise.

No. RED partners with Tower Semiconductor to design and manufacture CMOS sensors.

Being an action camera, GoPro really needs an All-Intra codec to combat compression artifacts in high action scenes. Maybe in the future Hero 12 as 11 only has UHS-I interface. With UHS-II you have V90 cards which means theoretical maximum 720Mbps bitrate.

400Mbps All-I codec would be nice. And option to completely turn off sharpening.

https://canon.jp/business/solution/indtech/cmos/lineup LI7080SA Super 35mm 4K: 14Bit 120fps, DGO support and 16+ stops of dynamic range. Double the readout speed compared to C300M3's 6.4μm 4K/60fps DGO and stable power consumption. A professional high-performance Super 35mm 4K 120fps high dynamic range sensor that can take on full frame. LI5030SA Global shutter FF 5.7K: 170Ke- large FWC (equivalent to ISO54), 1.8e-rms at 18dB gain (equivalent to ISO160), 15EV dynamic range, stable power consumption, with RGB/monochrome/RGB-IR/CFA-free versions. One of the top performing global shutter sensor, no image quality compromise compared to regular sensors, however readout speed is on the slower side - 5.7K 1.9:1 12bit 64fps.

Alexa is no longer the gold standard for non global shutter performance. It's Sony VENICE 2, it has 3ms rolling shutter. The latest Alexa 35 is 8ms, Alexa Classic and LF both ~7ms, Alexa 65 ~16ms.

https://www.dpreview.com/news/6357713219/atomos-ceo-reveals-more-details-of-the-company-s-full-frame-8k-global-shutter-image-sensor

1. The pixel-level read node design is similar to IMX610, only the implementation is different and dictates that it has fast conventional read speeds. 2. The physical pixels are 49 megapixels and the entire sensor is natively designed to be 49 megapixels, reusing the 4.2um BSI pixel design and using both analogue binning and digital binning together to achieve a 12 megapixel sensor. 3. IMX510 disables the all-pixel readout mode, so there is no possibility of an all-pixel readout, and naturally it cannot achieve 2x2 OCL AF, which is the biggest difference between it and IMX472. 4. Dividing IMX510's logical pixel into four physical pixels. The readout is achieved using 1:2 analogue binning before PGA and digital binning after ADC. The specifics are: A. 48 physical megapixels, divided into upper left, upper right, lower left and lower right in-group pixels. B. 24 mega pixels are read, binned in the form of upper left + lower right, upper right + lower left, dual stream 14bit readout. C. 2:1 pixel binning in the digital domain to generate 12 megapixels at 15bit, discard 1bit to 14bit output. D. The readout speed is around 21ms, approximating 48fps; when the precision is reduced to 12bit, 96fps can be achieved. E. The ADC does not have an 11bit mode, so it cannot achieve the faster 24M 11bit -> 12M 12bit. F. The digital binning discards 1bit of precision regardless of the mode of output, a waste of performance deliberately designed into IMX510. G. In one video mode, the internal readout of two 3.84K/128fps 12Bit ADC streams are digitally binned, but the resolution is not twice that of 3.84K. The precision and resolution are wasted. 5. Due to the uniqueness of the readout mode, IMX510 cannot achieve any 2x1 OCL in-group AF, and the orthogonal readout pixel groups cannot be used for phase detection. Therefore the only phase focusing design for the IMX510 is masked PDAF. A focusing method using 2x2 OCL AF will only be available when the all-pixel readout mode is unlocked. 6. The hardware performance of the sensor goes well beyond the limitations of the "IMX510" name. 7. If this sensor were to be a normal Bayer sensor, the readout speed would depend only on the total number of analogue pixels before the ADC, due to the pixel readout design. Thus 48 megapixels at 24fps 14bit. For this a Modified Bayer CFA can be used, which is suitable for pixel designs with 2:1 analogue signal binning - maximising its performance and enabling dual mode switching between high resolution and oversampled high speed shooting: Crop to 16:9 to achieve 8.5K/57.7fps 12bit, 2x4.35K/115.5fps 12bit respectively; crop slightly to 7.68K/64fps 12bit, 2x3.84K/128fps 12bit. Notably, its 2x3.84K/128fps 12Bit readout truly has double the resolution and achieves IMX301-like oversampling performance (Sony F65RS). 8. The readout speed of any column-parallel ADC design of an image sensor must be scaled by the line readout speed, by the total number of pixels multiplied by the number of columns, and at the same level of precision comparing: A 48 megapixel 14bit 24fps sensor reads at a larger scale than a 12 megapixel 14bit 48fps sensor, but we cannot call it a greater total number of pixels read out, but rather a faster readout, measured by miliseconds. At a given precision, readout time (the time taken to read a frame), readout scale (how many pixels are read in a second), and readout speed (how many rows of pixels can be read in a second by a column of ADCs), are three dintinctly different and important metrics.

Because the other advantage of the glass lens mod is that it has no distortion. The closest mode is "wide" that does not engage the software distortion correction (it's going to distort the already linear image if using "linear"). The slight zoom is only around 1.1x, the effect on softness and image resolution is negligible.

Comparison of the glass lens mod and original plastic lens: The stock lens is evidently more hazy and less detailed, demonstrated here and by some of the face crops in a previous reply. Look at the power lines, poles and especially the inscription text.

The stock lens on GoPro is plastic with evident haloing and softness. A third party all-glass lens mod is available (Hero 10 for now): https://www.peauproductions.com/collections/peaupro-cameras/products/peaupro14-gopro-hero-10-black-ribcage

The Labs firmware allows for 2 to 200Mbps arbitrary bitrate configuration. However at maximum 200Mbps, the camera can lock up at times. It also works for previous generation Hero cameras as well.

Great finding. But the "Smooth Skin Effect" is a blur effect only, it was added to GFX cameras a long time ago, it does not affect colour. Default is off and it has to be switched on.

Thanks. There seems to be very little, if any, difference between X-H2s and X-T3 in this clip.

It also means that the F-log banding/colour botch issue still exists, also for F-log2.

Because the photosenstive layer of the new X-Trans V HS is essentially the same as X-Trans IV, hence their colorimetry is the same so F-log implementation was copied over.

DJI Pro will be announcing a new camera product on 15 June:

It's not fake. Nobody said it IS the sensor of X-H2S, which is based on that sensor but with Fujifilm's customisation.

Yes it would have been much better for the users, but Sony didn't go that route from an R&D and markerting perspective. Sony already has BSI 4.2um products, so it would be easier than developing 8.4um products from scratch. Not unlocking 48MP mode seems to be product segmentation strategy, no a sacrifice due to technical capability.

The 7K readout has more noise to begin with. The difference in low light with modern FF sensors from Sony Semicon is very small.

Pixel binning reduces read noise (1 readout instead of 4), hence those 100MP+ smartphone sensors output 12MP in lowlight. A7S3 essentially uses it as a locked down 12MP sensor. In other words, it performs just as good as same-gen higher pixel FF sensor in A1, there's no longer a need to sacrifice pixel count for low light performance. But if you compare it to A7S2 or original A7S, the noise performance at lower ISO did get worse, because the higher readout speed requires multiple parallel ADCs and this slightly increases read noise. But at higher ISO they share negligible difference.

Pixel binning reduces read noise (1 readout instead of 4), hence those 100MP+ smartphone sensors output 12MP in lowlight. It's essentially used as a locked down 12MP sensor.
