kgv5 Posted November 9, 2016 Share Posted November 9, 2016 I have done some measurments of recording times with the newest build (with fine resolution settings) Everything tested with 24fps 10bit on 5d3 113, CF sandisk extreme pro 128gb 160mb/s. 1320 is the maximum vertical resolution for 5d3 when recording raw video. 3168x1320 2.40:1 (1.81x crop) - 14 sec 3104x1320 2.35:1 (1.85x crop) - 18 sec 3104x1298 2.39:1 (1.85x crop) - 21 sec 3008x1280 2.35:1 (1.91x crop) - 38 sec 3008x1258 2.39:1 (1.91x crop) - 56 sec 2976x1266 2.35:1 (1.93x crop) - 60 sec 2976x1246 2.39:1 (1.93x crop) - 123 sec 2880x1226 2.35:1 (2x crop) - continous And wider aspect ratios - just for fun: 3520x1320 2.67:1 (1,63x crop) - 6 sec 3296x1320 2.50:1 (1.74x crop) - 12 sec Now I would like to see the comparison: 5d3 vs 5d4 - raw 10bit 3008x1258 (quite usable recording time - 56 sec) vs MJPEG 8bit 4k. Not so much different crops - 1.91x 5d3 vs 1.7x 5d4. Similar bitrates. That would be very interesting. samuel.cabral, Dan Wake and Taranis 3 Quote Link to comment Share on other sites More sharing options...
Dan Wake Posted November 9, 2016 Share Posted November 9, 2016 what is it fine resolution settings? I tryed 12 bit and 10 bit on 7D but the files are 100% corrupted, I have load it from mlv lite 1.1 module. can you suggest me the default setting to make it work please? I'm doing it in no-crop mode, global drow off, tryed also to change ml preview options and nothing change. which sofftware do you use to convert mlv into dng? I did a test with mlrawviewr (it doesn't open the files but the problem should be related to mlv lite), and mlv producer. thx a lot Quote Link to comment Share on other sites More sharing options...
kgv5 Posted November 9, 2016 Share Posted November 9, 2016 Fine resolution settings - i mean there is ability to change recording resolution in smaller steps, around 30 pixels or so.. Normally it was 2880 x something and next 3540 x something, now you can choose many options in between. So you had continous 2880 and than couple of seconds of 3540. Now it is very nice to adjust horizontal resolution precisely. I use 5d3 and it has no problems with pink artifacts, i dont know about 7d but i think it doesnt have fully working version yet. And i use old version of mlvfs on pc - the one with pismo, i just quick-mount mlvs and open them in resolve, no extracting. Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
Taranis Posted November 10, 2016 Share Posted November 10, 2016 10 hours ago, kgv5 said: I have done some measurments of recording times with the newest build (with fine resolution settings) Everything tested with 24fps 10bit on 5d3 113, CF sandisk extreme pro 128gb 160mb/s. 1320 is the maximum vertical resolution for 5d3 when recording raw video. 3168x1320 2.40:1 (1.81x crop) - 14 sec 3104x1320 2.35:1 (1.85x crop) - 18 sec 3104x1298 2.39:1 (1.85x crop) - 21 sec 3008x1280 2.35:1 (1.91x crop) - 38 sec 3008x1258 2.39:1 (1.91x crop) - 56 sec 2976x1266 2.35:1 (1.93x crop) - 60 sec 2976x1246 2.39:1 (1.93x crop) - 123 sec 2880x1226 2.35:1 (2x crop) - continous And wider aspect ratios - just for fun: 3520x1320 2.67:1 (1,63x crop) - 6 sec 3296x1320 2.50:1 (1.74x crop) - 12 sec Now I would like to see the comparison: 5d3 vs 5d4 - raw 10bit 3008x1258 (quite usable recording time - 56 sec) vs MJPEG 8bit 4k. Not so much different crops - 1.91x 5d3 vs 1.7x 5d4. Similar bitrates. That would be very interesting. I'd love to see some outdoor shots with this high resolution. Quote Link to comment Share on other sites More sharing options...
gatopardo Posted November 15, 2016 Share Posted November 15, 2016 Anyone successful with the 600d ? I've tried with one but no luck. Sure I'm doing something wrong, Any help? Quote Link to comment Share on other sites More sharing options...
hyalinejim Posted November 15, 2016 Share Posted November 15, 2016 More good news (well, for certain shooters). A1ex is on the way to fixing the off-centre 5x zoom crop centering. If you weren't aware, in the "5x" grayscale preview crop mode (the one that allows you to bump up the resolution) the portion of the sensor that was being sampled was not exactly in the middle. And the more you'd increase resolution, the more off center it would become. This was a PITA for those who are trying to make precise geometric compositions in this mode as it was impossible to get a symmetrical planimetric framing, or for anyone who wanted to use an anamorphic in crop mode as you would start hitting the vignetting on one side. It isn't in the nightly builds yet, but is on the way. http://www.magiclantern.fm/forum/index.php?topic=17021.msg174866#msg174866 kaylee and Dan Wake 2 Quote Link to comment Share on other sites More sharing options...
Dan Wake Posted November 15, 2016 Share Posted November 15, 2016 5 hours ago, hyalinejim said: More good news (well, for certain shooters). A1ex is on the way to fixing the off-centre 5x zoom crop centering. If you weren't aware, in the "5x" grayscale preview crop mode (the one that allows you to bump up the resolution) the portion of the sensor that was being sampled was not exactly in the middle. And the more you'd increase resolution, the more off center it would become. This was a PITA for those who are trying to make precise geometric compositions in this mode as it was impossible to get a symmetrical planimetric framing, or for anyone who wanted to use an anamorphic in crop mode as you would start hitting the vignetting on one side. It isn't in the nightly builds yet, but is on the way. http://www.magiclantern.fm/forum/index.php?topic=17021.msg174866#msg174866 do you mean will be possible to shoot in crop mode having a colored preview with good refresh rate (fps)? because now to have precise framing the only solution is to use grayscale preview, this mode allow precise framing but kills fps refresh rate and is black and white. thx Quote Link to comment Share on other sites More sharing options...
hyalinejim Posted November 15, 2016 Share Posted November 15, 2016 No, unfortunately. This mode is still not good for shooting styles that require any level of response in real time. However, I seem to recall that if you half press the shutter button (at least on the 5d3) you get a colour preview and slightly faster fps. This helps a bit but it's still tricky if you need to follow fast moving action. Quote Link to comment Share on other sites More sharing options...
Dan Wake Posted November 15, 2016 Share Posted November 15, 2016 57 minutes ago, hyalinejim said: No, unfortunately. This mode is still not good for shooting styles that require any level of response in real time. However, I seem to recall that if you half press the shutter button (at least on the 5d3) you get a colour preview and slightly faster fps. This helps a bit but it's still tricky if you need to follow fast moving action. maybe I have misunderstand your previous post because I have not understand what is going to change. can you explain again please? I'm sorry or my english Quote Link to comment Share on other sites More sharing options...
gatopardo Posted November 15, 2016 Share Posted November 15, 2016 8 hours ago, gatopardo said: Anyone successful with the 600d ? I've tried with one but no luck. Sure I'm doing something wrong, Any help? Done! It's great Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
hyalinejim Posted November 15, 2016 Share Posted November 15, 2016 @Dan Wake previously, in 5x greyscale crop mode the cropped area was not in the middle of the sensor. It was to the left. Soon that will be fixed. Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
tweak Posted November 15, 2016 Share Posted November 15, 2016 So still no working 7D build as I understand it? Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
Dan Wake Posted November 29, 2016 Share Posted November 29, 2016 saw this yesterday night, a very nice calculator for ML raw video! http://www.magiclantern.fm/forum/index.php?topic=18326.0 Quote Link to comment Share on other sites More sharing options...
Justin Bacle Posted November 29, 2016 Share Posted November 29, 2016 3 hours ago, Dan Wake said: saw this yesterday night, a very nice calculator for ML raw video! http://www.magiclantern.fm/forum/index.php?topic=18326.0 Great, thank you for sharing Last time I checked (17/11 nightly build) the 10 & 12 bit recording weren't working on the 50D but i'll try again as soon as there is another build. Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
Administrators Andrew Reid Posted November 30, 2016 Administrators Share Posted November 30, 2016 On 11/29/2016 at 9:33 AM, Dan Wake said: saw this yesterday night, a very nice calculator for ML raw video! http://www.magiclantern.fm/forum/index.php?topic=18326.0 Interesting the 5DS and 5DIV are on there. ML isn't The 5DS actually shoots quite nice 1080p. It will be a contender if they end up porting ML RAW to it. Dan Wake 1 Quote Link to comment Share on other sites More sharing options...
Administrators Andrew Reid Posted June 22, 2017 Administrators Share Posted June 22, 2017 What apps are you guys using to convert compressed RAW 10bit MLV to DNG on a Mac? I have searched for a few and only Mystic beta 0.5 works so far - but there are green focus pixels all over the frame on the 100D. Quote Link to comment Share on other sites More sharing options...
Administrators Andrew Reid Posted June 22, 2017 Administrators Share Posted June 22, 2017 UPDATE: Ah got it. MLVFS. Blog post coming. Shooting continuous 10bit video on the £250 Canon 100D at close to 1.8k in 2.35:1 Quote Link to comment Share on other sites More sharing options...
mercer Posted June 22, 2017 Share Posted June 22, 2017 If you don't want to use MLVFS, Raw Magic works really well and can be bought through the App Store. Quote Link to comment Share on other sites More sharing options...
Administrators Andrew Reid Posted June 22, 2017 Administrators Share Posted June 22, 2017 7 minutes ago, mercer said: If you don't want to use MLVFS, Raw Magic works really well and can be bought through the App Store. Raw Magic is great but it doesn't support the new 10bit / 12bit compressed RAW yet... At least my version didn't...? Quote Link to comment Share on other sites More sharing options...
