Isco anamorphot 1.5x Focus Diopter


Simon Cote
 Share

Recommended Posts

I have this Isco Anamorphot 1.5x. I really like the dreamy feel of it. But it's quite hard to focus things that are maybe 3-5 ft away (whitout any diopters). I get sharp closeup with the 40mm dioptier that came with it but then I can only do close-up cannot focus to infinity. I see people uses a +0.5 diopter to maybe +1 diopter to get sharper images with their Anamorphic lenses. Is there a good diopter option I could get so I could still get the infinity focus and be able to close focus (without being big close-ups) Anyone can help me out ?

Close-up with the 40mm diopter

Capture d’écran 2016-11-29 à 13.21.27.png



without diopter I can't focus right when closer to the subject! It would be perfect If I could focus that close and then get infinity alsoCapture d’écran 2016-11-29 à 13.24.41.png

Link to comment
Share on other sites

EOSHD Pro Color 5 for Sony cameras EOSHD Z LOG for Nikon CamerasEOSHD C-LOG and Film Profiles for All Canon DSLRs
32 minutes ago, SigurdW said:

If I understand your question correctly, do some research on:

SLR Magic Rangefinder, Rectilux CoreDNA or FM Lens (Focus Module).

These products allows a focusing range from ≈1 meter to infinity. They all have their strengths and weaknesses.

Hey SigurdW, thanks for the reply. These solution are all quite expensive I thought I could simply use a diopter that could help me to get a closer focus distance while keeping the ability to focus to infinity without having to unscrew that diopter.



Cheers

Link to comment
Share on other sites

21 hours ago, Simon Cote said:

Hey SigurdW, thanks for the reply. These solution are all quite expensive I thought I could simply use a diopter that could help me to get a closer focus distance while keeping the ability to focus to infinity without having to unscrew that diopter.



Cheers

What you want is impossible, as a diopter always limits your maximum focus distance. So no infinity, but closer focus yes. Read up on Tito's site http://www.tferradans.com/blog/?p=7282
